OUTPUT Command (continued)
Response (optional)
RSP,OUT,psn,err,checksum<CR><LF>
OUTPUT Response Message Format
Parameter Description
RSP, Start of Message string (This parameter is always “RSP”).
OUT, Output Response string (This parameter is always “OUT”).
psn, Packet Sequence Number. Matches command packet sequence number.
err, Error Number (0 to 999). 0 = okay, else number indicating problem
checksum Checksum (0 to 65535). Unsigned 16-bit decimal sum of all preceding characters
<CR> Terminating carriage return. (ASCII control character, 0x0D)
<LF> Terminating line feed. (ASCII control character, 0x0A)
OUT Command & Response Example
Command
CMD,OUT,0,MSKFLAT,Y,1347<CR><LF>
Response
RSP,OUT,0,0,765<CR><LF>
96
eCNA-10 Operation and Installation Manual Version 1.270-00
