EVENT Log (continued)
This is a list of events and their definitions.
Events
Event
No.
Event Name Description
1 StartMan
Manual Start - Remote (LIN) start, Keyboard start and Sync start (slave).
Event ‘Type’ Flag bits set: Any Event (16), Show Start (24), Scheduled Event (30)
4 Show_End
Show End - Transition from “In Progress” to “Idle”
Event ‘Type’ Flag bits set: Any Event (16), Show End (23), Scheduled Event (30)
5 IntmStrt
Intermission Start - Programmed intermission
Event ‘Type’ Flag bits set: Any Event (16), Scheduled Event (30)
6 Intm_End
Intermission End - Cue or Start or Timer
Event ‘Type’ Flag bits set: Any Event (16), Scheduled Event (30)
7 Stop_Man
Manual Stop - Remote (LIN) stop, Keyboard stop
Event ‘Type’ Flag bits set: Any Event (16), Unscheduled Shutdown (29)
8 Resumed
Show Resumed
Event ‘Type’ Flag bits set: Any Event (16), Resume (21)
9 ReadyRun
Ready to Run - Not in progress and no faults
Event ‘Type’ Flag bits set: Any Event (16), Ready to Run (19)
12 MemSuper
Supervisory Memory Fault
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Computer (28), Unscheduled Shutdown
(29)
14 MemProg
Program Memory Fault
P1 = Program Number
P2 = Step Number
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Computer (28), Unscheduled Shutdown
(29)
16 XenonFlt
Xenon Lamp Fault
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Unscheduled Shutdown (29)
17 LIN_Flt
Local I/O Network Fault
P1 = LIN device ID
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Unscheduled Shutdown (29)
23 StopFire
Fire Stop Fault
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Unscheduled Shutdown (29)
24 Stop_Rem
Remote Stop - LSN RSM-10, LSN sync stop
Event ‘Type’ Flag bits set: Any Event (16), Major Fault (27), Unscheduled Shutdown (29)
25 ReadyRes
Ready to Resume Fault
Event ‘Type’ Flag bits set: Any Event (16), Ready to Resume (18)
26 Battery
Low Battery Fault. Real Time Clock chip lost battery backup
Event ‘Type’ Flag bits set: Any Event (16), Minor Fault (25), Computer (28)
33 ResetExt
External Reset. (Parameters 1 through 6 are the captured old time.)
P1 = Year
P2 = Month
P3 = Day
P4 = Hour
P5 = Minutes
P6 = Seconds
P7 = Firmware Version
P8 = Firmware Checksum
Event ‘Type’ Flag bits set: Any Event (16), Computer (28), Unscheduled Shutdown (29)
34 ResetPup
Power up Reset. (Parameters 1 through 6 are the captured old time.)
P1 = Year
P2 = Month
P3 = Day
P4 = Hour
P5 = Minutes
P6 = Seconds
P7 = Firmware Version
P8 = Firmware Checksum
Event ‘Type’ Flag bits set: Any Event (16), Computer (28), Unscheduled Shutdown (29)
35 ResetDog
Watchdog Reset. (Parameters 1 through 6 are the captured old time.)
P1 = Year
P2 = Month
P3 = Day
P4 = Hour
P5 = Minutes
P6 = Seconds
P7 = Firmware Version
P8 = Firmware Checksum
Event ‘Type’ Flag bits set: Any Event (16), Computer (28), Unscheduled Shutdown (29)
113
eCNA-10 Operation and Installation Manual Version 1.270-00
