© EPRAD Incorporated
EVENT Log (continued)
Events (continued)
Event
No.
Event Name Description
95 Macxxayy
Macro Call
Mac = constant and indicates a macro was executed.
xx = macro number (01 to 50)
a = P for program, C for CAI Command, T for Trigger, M for Macro, D for Debug Execute Macro
Button
yy = Program number (01-99), CAI Channel number (01-04), Trigger number (01-30)
P1 = Macro Number (01-50)
P2 = Owner (0 = Program, 1 = CAI, 2 = Trigger, 3 = Macro)
P3 = Program Number
P4 = Program Step Number
P5 = CAI Channel Number
P6 = Trigger Number
P7 = Status (0 = Ok, 1 = Error due to macro call recursion limit)
Event ‘Type’ Flag bits set: Any Event (16)
96 SENDF1
CAI SENDF1 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
97 SENDF2
CAI SENDF2 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
98 SENDF3
CAI SENDF3 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
99 SENDF4
CAI SENDF4 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
100 SENDF5
CAI SENDF5 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
101 SENDF6
CAI SENDF6 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
102 SENDF7
CAI SENDF7 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
103 SENDF8
CAI SENDF8 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
104 Xifmm_nn
Exit If Instruction
mm = Macro number (01-50)
nn = Macro step number (01 - 15)
P1 = Macro number (01-50)
P2 = Macro step number (01 - 15)
P3 = Destination Step number or 0 for exit
Event ‘Type’ Flag bits set: Any Event (16)
105 VoltHiLo
Line Voltage Hi/Lo
P1 = Highest voltage measured during the interval
P2 = Lowest voltage measured during the interval
Event ‘Type’ Flag bits set: Any Event (16)
106 SENDF9
CAI SENDF9 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
107 SENDF10
CAI SENDF10 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
108 SENDF11
CAI SENDF11 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
109 SENDF12
CAI SENDF12 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
110 SENDF13
CAI SENDF13 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
111 SENDF14
CAI SENDF14 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
112 SENDF15
CAI SENDF15 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
113 SENDF16
CAI SENDF16 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
114 SENDF17
CAI SENDF17 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
115 SENDF18
CAI SENDF18 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
116 SENDF19
CAI SENDF19 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
117 SENDF20
CAI SENDF20 Event Report
Event ‘Type’ Flag bits set: Any Event (16)
116
eCNA-10 Operation and Installation Manual Version 1.270-00
