EPRAD eCNA-10 - Termination Board Input Wiring Options

© EPRAD Incorporated
TB5 is the inputs and remote power connections.
TB5 Name Description / Comment
1 Start A
Software configurable. Default = Remote Start input
2 Start B
3 Stop A
Software configurable. Default = Remote Stop Input
4 Stop B
5 Fire Stop A
Fire Alarm System input
6 Fire Stop B
7 Digital 1 Cue A
Cue input
8 Digital 1 Cue B
9 IN 1 A
These four input are software configurable.
10 IN 1 B
11 IN 2 A
12 IN 2 B
13 IN 3 A
14 IN 3 B
15 IN 4 A
16 IN 4 B
17 (+) 12VDC Power
+12VDC Power (fused at 1/4 amp)
18 (+) 12VDC Power
19 (-) 12VDC Return
20 (-) 12VDC Return
