9) Alarm The internal alarm is used to alert booth personnel that a show has stopped due to an
equipment malfunction. The alarm is configured from the System Parameters screen.
Configuration DIP Switches
S1 Function ON OFF
S1-1 Boot Loader Force Boot Loader on Power Up Application on Power Up *
S1-2 Supervisory Defaults Force Factory Defaults on Power Up Do Not Overwrite *
S1-3 Screen Id 20H bit Value = 20H (32 Decimal) Value = 00H (0 Decimal) *
S1-4 Screen Id 10H bit Value = 10H (16 Decimal) Value = 00H (0 Decimal) *
S1-5 Screen Id 08H bit Value = 08H (8 Decimal) Value = 00H (0 Decimal) *
S1-6 Screen Id 04H bit Value = 04H (4 Decimal) Value = 00H (0 Decimal) *
S1-7 Screen Id 02H bit Value = 02H (2 Decimal) Value = 00H (0 Decimal) *
S1-8 Screen Id 01H bit Value = 01H (1 Decimal) * Value = 00H (0 Decimal)
S2 Function ON OFF
S2-1 Manual Control Screen Enable * Disable
S2-2 Password Enable * Disable
S2-3 Check Focus Delay Alarm Enable Disable *
S2-4 Fire Stop Enable Disable *
S2-5 Not Defined Not Defined Not Defined *
S2-6 Not Defined Not Defined Not Defined *
S2-7 Host Event Log Enable * Disable
S2-8 Cinema Automation Interface Enable * Disable
S3 Function ON OFF
S3-1 Not Defined Not Defined Not Defined *
S3-2 Not Defined Not Defined Not Defined *
S3-3 Not Defined Not Defined Not Defined *
S3-4 Not Defined Not Defined Not Defined *
S3-5 Not Defined Not Defined Not Defined *
S3-6 Check Focus Delay Alarm (Remote) Disable RCM / RSM Alarm on Start * Enable RCM / RSM Alarm on Start
S3-7 Not Defined Not Defined Not Defined
S3-8 IP Defaults Force Defaults on Power Up Do Not Overwrite *
* Default
U
Note: All DIP switches are read by the application once at power up. Changing the
switches while the unit is powered on will not have an effect until the power is cycled.
