The relay Outputs can be assigned to any of the control flags in the table.
Name Description
<<Blank>>
DP1 Pwr Off Controlled by Digital Projector 1 Power Off output control flag
DP1 Pwr On Controlled by Digital Projector 1 Power On output control flag
DP1 Vid Off Controlled by Digital Projector 1 Video Off output control flag
DP1 Vid On Controlled by Digital Projector 1 Video On output control flag
DP2 Pwr Off Controlled by Digital Projector 2 Power Off output control flag
DP2 Pwr On Controlled by Digital Projector 2 Power On output control flag
DP2 Vid Off Controlled by Digital Projector 2 Video Off output control flag
DP2 Vid On Controlled by Digital Projector 2 Video On output control flag
In Progress Controlled by eCNA-10’s In Progress control flag
Fault Controlled by eCNA-10’s Major Fault control flag
Fire Stop Controlled by eCNA-10's Fire Stop control flag
H. Lights Down Controlled by House Lights Down output control flag
H. Lights Mid 1 Controlled by House Lights Mid 1 output control flag
H. Lights Mid 2 Controlled by House Lights Mid 2 output control flag
H. Lights Up Controlled by House Lights Up output control flag
S. Lights Down Controlled by Stage Lights Down output control flag
S. Lights Up Controlled by Stage Lights Up output control flag
Curtain Open Controlled by Curtain Open output control flag
Curtain Close Controlled by Curtain Close output control flag
Mask Flat Controlled by Masking output control flag
Mask Scope Controlled by Masking output control flag
Mask Special Controlled by Masking output control flag
Lens Flat Controlled by Lens output control flag
Lens Scope Controlled by Lens output control flag
Lens Special Controlled by Lens output control flag
Sound Aux 1 Controlled by Sound output control flag
Sound Aux 2 Controlled by Sound output control flag
Sound Digital 1 Controlled by Sound output control flag
Sound Digital 2 Controlled by Sound output control flag
Sound Mono Controlled by Sound output control flag
Sound Mute Controlled by Sound output control flag
Sound Non-Sync Controlled by Sound output control flag
Sound SR Controlled by Sound output control flag
Sound SVA Controlled by Sound output control flag
Slide Projector Controlled by Slide Projector output control flag
Out 1 - Out 16 Controlled by Out output control flags
In 1 - In 16 Controlled by the In input control flags
48
eCNA-10 Operation and Installation Manual Version 1.270-00
