Setup & Operation 12. Option Units

98 RC180 Rev.17

Electronic Information File (CSP file)

A CSP file is supplied for CC-Link network configuration. The file is located in the

following folder in the Manual Update CD that is attached to the Robot Controller.

\EpsonRC50\Fieldbus\CCLink
