Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
PRODUCT DESCRIPTION Specification for Each Function 47
Confidential
Figure 1-16. SX210 series の Nozzle Check Pattern
*
Note* : The numbers shown in the figure are nozzle numbers. The numbers and the color names
are not printed on an actual nozzle check pattern.
Table 1-55. Setup Mode Menu for SX210 series
Item Function
Nozzle Check
A nozzle check pattern to check the Printhead nozzles status is
printed. A head cleaning can be run if necessary. (Refer to
Figure 1-16.)
Head Cleaning
Runs a printhead cleaning. The cleaning cannot be made when
low ink level is detected. In such a case, an ink low error is
displayed instead of running the cleaning.
Head Alignment
Adjustment to improve the bi-directional print quality. Head
alignment icon and the instructions for the adjustment are
displayed on the LCD.
Cartridge Replacement
Runs an ink cartridge replacement sequence. This can be done
from the Ink Cartridge Status menu or by following the
instructions on the LCD when an ink-related error occurs.
Language Sets the language.
Restore Default Settings Restores the default settings of the panel settings.
8 dots
360 dpi VSD1 dot
0.212mm (1/120inch)
Cyan
Magenta
Yellow
Black
To Next Page
