EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 228
Confidential
A
Figure 6-9. Ink System Mechanism
No. Part/Component No. Part/Component No. Part/Component No. Part/Component
1 Ink Eject Cover (p. 378) 4 Porous Pad Cap Lower (p. 378) 7 --- 10 ---
2
Maintenance Box Detect Sensor Assy
(p. 378)
5 --- 8 --- 11 ---
3 Inksystem Unit (p. 378) 6 --- 9 --- 12 ---
1
3
4
2
