EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 255
Confidential
DISASSEMBLY FLOWCHART
A1
E1
B1
F1
C1
Start
Rear Back Cover
(→P. 256)
Start
Rear Upper Cover Assy
(→P. 257)
Housing ASF
(→P. 259)
Printer Cover
(→P. 259)
Housing Right
(→P. 260)
A3
D1
A2
E2
B2
F2
C2
D2
Paper Guide
(→P. 258)
B3
E3 F3D3
E4 F4D4
Ink Eject Cover
(→P. 260)
E5 F5D5
E6 F6
ASF Cover
(→P. 257)
D6
Housing Left
(→P. 261)
E7 F7
Housing Top
(→P. 261)
F8E8
Cover Open Sensor
(→P. 262)
F9
C3
Paper Guide
(→P. 258)
C4
C5
Housing Rear
(→P. 258)
