Epson WF-C5790 User Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Adjustment Adjustment and Inspection Details 562
Confidential
4. Move the CR unit to the thickness gauge and check whether or not the CR
Unit touches the thickness gauge.
• If does not touch the thickness gauge: Proceed to step 5.
• If touches the thickness gauge: Perform the adjustment in the
procedure below.
4-1. Move the CR unit to the center part of the printer.
4-2.Move the PG adjustment cam on the right side by one notch in the “+”
direction.
4-3. Move the CR unit to the thickness gauge again and check whether or not
the carriage touches the thickness gauge.
• If touches the thickness gauge, repeat the work of Step 4-1 to Step 4-3
until the CR Unit does not touch the thickness gauge.
5. Place the thickness gauge (1.42 mm thickness gauge + 0.08 mm Teflon tape)
at position B shown in Figure 7-4.
•Even for the Full digit side, follow the same procedure to adjust the PG
adjustment cam on the left side until the CR Unit is no longer in contact
with the thickness gauge.
6. Place the thickness gauge (1.62 mm thickness gauge + 0.08 mm Teflon tape)
at position A shown in Figure 7-4.
7. Move the CR unit to the thickness gauge and check whether or not the
carriage touches the thickness gauge.
• If touches the thickness gauge: Proceed to step 8.
• If does not touch the thickness gauge: Perform the adjustment in the
procedure below.
7-1. Move the CR unit to the center part of the printer.
7-2.Move the PG adjustment cam on the right side by one notch in the “-”
direction.
7-3.Move the CR unit to the thickness gauge again and check whether or not
the CR Unit touches the thickness gauge.
• If does not touch the thickness gauge, repeat the work of Step 7-1 to
Step 7-3 until the CR Unit touches the thickness gauge.
8. Place the thickness gauge (1.62 mm thickness gauge + 0.08 mm Teflon tape)
at position B shown in Figure 7-4.
•Even for the Full digit side, follow the same procedure to adjust the PG
adjustment cam on the left side until the CR Unit comes in contact with the
thickness gauge.
9. Tighten the two fixing screws of the PG adjustment cam positioned on the left
and right, and the four fixing screws of the CR guide frame.

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
