CEM+ Procedures 43
Switched
Switched mode defaults to full unregulated sine wave of the power through the dimmer. This is good
for inductive loads connected to a dimmer.
Change the firing mode to Switched and click Save Changes. After saving changes, the remaining
dimmer properties will change automatically or can now be set to your desired values.
Non-Dim
Non-dim mode is not offered in CEM+ as it was in classic CEM, but you can re-create it with the
settings listed below.
Non-dim is a voltage regulated version of switched mode. Switched mode delivers full sine wave power
through the dimmer, good for inductive loads. Non-dim regulates (dims) the output to a user specified
value, protecting on/off lamps from unregulated power in venues where mains exceed lamp ratings.
Non-dim operation may be accomplished using switched mode and enabling voltage regulation and
adjusting max scale voltage (see table below).
Property 120V 230V
Firing Mode Switched Switched
Curve Linear Linear
Threshold 50% 50%
Min. Scale Voltage 0V 0V
Max. Scale Voltage 140V 280V
Voltage Regulation Unchecked Unchecked
Preheat Unchecked Unchecked
Dynamic Preheat 0 sec. 0 sec.
DC Output Prevent Unchecked Unchecked
InRush Protect Unchecked Unchecked
Property 120V 230V
Firing Mode Normal Normal
Curve Linear Linear
Threshold
1%
or desired setting
1%
or desired setting
Min. Scale Voltage
115V
or desired setting
230V
or desired setting
Max. Scale Voltage
115V
or desired setting
230V
or desired setting
Voltage Regulation Checked Checked
Preheat Unchecked Unchecked
Dynamic Preheat 0 sec. 0 sec.
DC Output Prevent Unchecked Unchecked
InRush Protect Unchecked Unchecked
