44 Sensor+ CEM+ User/Config Manual
Fluorescent
Change the firing mode to Fluorescent and click Save Changes. After saving changes, the remaining
dimmer properties will change automatically or can now be set to your desired values.
Always On
Change the firing mode to Always On and click Save Changes. After saving changes, the remaining
dimmer properties will change automatically or can now be set to your desired values.
Property 120V 230V
Firing Mode
Fluorescent Fluorescent
Curve Linear Linear
Threshold
1%
or desired setting
1%
or desired setting
Min. Scale Voltage
56V
or desired setting
56V
or desired setting
Max. Scale Voltage
120V
or desired setting
240V
or desired setting
Voltage Regulation Checked Checked
Preheat Unchecked Unchecked
Dynamic Preheat 0 sec. 0 sec.
DC Output Prevent Checked Checked
InRush Protect Unchecked Unchecked
Property 120V 230V
Firing Mode Always On Always On
Curve Mod-Square Mod-Square
Threshold 0% 0%
Min. Scale Voltage 140V 280V
Max. Scale Voltage 140V 280V
Voltage Regulation Unchecked Unchecked
Preheat Unchecked Unchecked
Dynamic Preheat 0 sec. 0 sec.
DC Output Prevent Unchecked Unchecked
InRush Protect Unchecked Unchecked
