Euphonix Max Air Mixing Console Operation Manual Channels and Strips
100
Stereo Controls
There are two additional controls used for stereo channels (see Multi Format Master
Channels on page 154).
Balance• : Rotate the Bal knob left to hear more of the left channel; rotate right to
hear more of their right channel. Rotate left or right until the display reads 100L or
100R to hear only the left or right channel.
Left-to-mono• : Press the upper key next to the Bal knob to send the left channel
equally to both the left and right sides of the stereo channel.
Right-to-mono:• Press the lower key next to the Bal knob to send the right channel
equally to both the left and right sides of the stereo channel.
Both-to-mono:• Press both keys next to the Bal knob to send a mono mix of both
channels equally to both sides of the stereo channel. The Bal knob then adjusts the
mix between left and right channels.
Swap:• Press the lower key to reverse the left and right channels.
On
On
On
On
Select
Select
Select
Select
Copy Paste
HiZ
48v
HPF
Gain
On
On
On
On
Select
Select
Select
Select
Copy Paste
Trim
Bal
Dly
Inpt
On
On
On
On
Select
Select
Select
Select
Copy Paste
Swap
Aphs
Bphs
Page 1Page 2 Page 3
Input Select
Delay
Mic Gain
A Input Phase
B Input Phase
B Input
A Input
On/Off
On/Off
On/Off
Right to Mono
Left to Mono
On/Off On/Off
On/Off
On/Off
Input Trim
Balance
Stereo Input KnobsetsFigure 5-9
