Patching Examples4.4
These examples assume that the steps in Mic/Line Interface Patching on page 58 have
been successfully completed.
Patch 12 Mics Into Channels 25–364.4.1
Select the Sources
Select the 1. Sources tab (1 in Figure 4-19).
Select Mic-Line 1 from the sub-categories (2 in Figure 4-19).2.
This displays all inputs from the rst Mic-Line Interface in the Name column. The
Mic-Line Interface is connected as part of the initial studio setup.
Select Mic1-1–Mic1-12 from the 3. Mic-Line column by touching and dragging
through the cells (3 in Figure 4-19).
These entries are highlighted in green in the Sources column of the Selected
Sources and Destinations area (4 in Figure 4-19). If there were more than 24
sources, additional tabs would appear to the right of the 1–24 tab.
Sources View with 12 Mic-Line Sources SelectedFigure 4-19
4
3
2
1
