Euphonix Max Air Mixing Console Operation Manual Event System
169
Event Conguration Display11.4
Access the Events View by selecting the Events Main Menu button. The Events View
has three sections: Inputs (1 in Figure 11-1), Event List (2), and Outputs (3).
Event ViewFigure 11-1
Event List11.5
An Event is composed of a set of input descriptions and types, a logical operator, and a
set of output descriptions and types. In the Event List, add an event to the list by touch-
ing the <Press to Add Event> eld at the bottom of the center Description column.
Name the event in the keyboard popup. Select the logical operator that will govern the
Event’s Inputs from the box in the Logic column.
CAUTION: Be aware that events can form a logic feedback loop.
5
4
3
2
1
