Euphonix Max Air Mixing Console Operation Manual Touchscreen
57
To complete this Patch example:
Select the 1. Sources tab (1 in Figure 4-13).
Touch and drag through the rst ve cells in the Frame 1-1 column (2 in Figure 2.
4-13).
Note that these names appear in the Sources column of the Selected Sources and
Destinations area next to their counterparts in the Destinations column (3 in in
Figure 4-13).
Sources and Destinations SelectedFigure 4-13
Touch the 3. Patch Selected button (4 in Figure 4-13) to make the Patch.
Note in Figure 4-14 that the Selected Sources and Destinations area is cleared (1
in Figure 4-14) and the A Input names appear next to their source channels (2 in
Figure 4-14).
4
3
2
1
