120 WT.050.570.000.DE.IM.0714
Functions DEPOLOX
®
Pool
2.6
Adaption sequence Each adaption phase is then displayed with a status message:
Various status messages can be output, depending on the selection of
the dosing equipment. Different status messages also have different
execution times. It is possible that several status messages are only
displayed briefly or not at all if the execution time is very short.
CAUTION!
Adaption can take up to 13 hours, depending on the control loop. Du-
ring this time no errors should occur on the control loop (e.g. filter back-
washing, changes in the circulation or widely fluctuating number of vi-
sitors).
NOTE
The adaption procedure can be terminated at any time with "BREAK".
The previously set parameters remain unchanged.
Display text: Explanation:
"0: Init" Start
"1: Ym = 0 %" Chlorinator to 0 % or dosing pump off
"2: X = 20 %" Delay until actual value < 0.2 x end value
"3: Ym = 100 %" Chlorinator to 100 % or dosing pump on
"4: Ym = 100 %" Wait until the chlorinator reaches 100 %
"5: Tu! " Start dead time measurement
"6: Tu! " Measurement of the loop dead time Tu
"7: Tu check " Plausibility enquiry dead time
"8: Init Ts " Start of rise time measurement
"9: Ts " Measurement of the loop rise time Ts
"10: Ts " Calculate control parameters
"11: Y = 0 %" Chlorinator to 0 % or dosing pump off
"12: Y = 0 %" Wait until the chlorinator reaches 0 %
"13: Adaption OK" End
