Evoqua DEPOLOX - Page 131

DEPOLOX
®
Pool Installation / Commissioning
WT.050.570.000.DE.IM.0714 131
2.7
No. Step Reference Compl.
If Redox measurement
available:
35
When CEDOX is used:
Set mV setpoint, set mV setpoint
ECO if necessary, check Xsh,
adjust if necessary,
check mV
delay, adjust if necessary
(Display 1.3.1)
36 Check limit values for Redox
("Min" and "Max"),
adjust if necessary
1.3.3
(Display 1.3.1)
37 Check measuring range for Re-
dox, adjust if necessary
1.3.3
(Display 1.3.2)
If Cl-N measurement available:
38 Check Cl-N parameter "max.
comb. chlor", adjust if necessary
1.3.3
(Display 1.4.1)
39 Check the "min ON" and "min
OFF" times of the enable contact
for activated powder carbon do-
sing systems or UV disinfection
units, adjust if necessary
1.3.3
(Display 1.4.1)
40 Check limit values for Cl-N ("Min"
and "Max"), adjust if necessary
1.3.3
(Display 1.4.2)
41 Check measuring range for Cl-N,
adjust if necessary
1.3.3
(Display 1.4.3)
