EXFO Optical Xplorer OX1 User Manual

Optical Xplorer 1
1 Introducing the OX1 Optical
Xplorer
The OX1 Optical Xplorer is a handheld, ultra-simple, and ultra-fast tool
offering multiple test functions to verify any short- to medium-length (up to
40 km) optical links and their components. It is particularly well suited for
installation and repair jobs.
Note: On your unit, the period is used as the decimal separator in numerical
values, when applicable.
Main Features
 Fiber length, loss and optical return loss (ORL) measured in a
single-ended process, in a few seconds
 Easy detection and location of common causes of failure with the Fault
Xplorer™ function
 Quality evaluation of the installations with EXFO Advisor™.
Measurements are rated using a five-star system.
 Replaceable Click-Out™ optical connector –Pro models only

EXFO Optical Xplorer OX1 Specifications

General

Brand	EXFO
Model	Optical Xplorer OX1
Category	Measuring Instruments
Language	English
