Maintenance
134 OX1
Replacing the Click-Out Optical Connector (Pro Models Only)
To remove the Click-Out optical connector:
1. Disconnect the fiber and USB cable from the unit, if applicable.
2. Position the unit so that you can see its Click-Out connector and easily
access it.
Click-Out connector’s
release tab
