Introducing the OX1 Optical Xplorer

Optical Xplorer 3

Main Features

Top panel

Bottom panel

Optical port (Pro model with

Click-Out optical connector shown)

USB 2.0 Type-C connector for

battery charging (see Power

Sources on page 6)
