Testing Fibers
76 OX1
Working With Link Results
By tapping directly on the space dedicated to the link results, you can
access the loss and ORL values by wavelength. The page displays also the
length for both the launch and receive test cords.
Note: If the link ORL value is displayed with a < symbol, the value is exceeding
the saturation level of the detector.
Note: If the reflectance value is displayed with a > symbol, the value is exceeding
the saturation level of the detector.
Link length
