1. Data Transmission between OBID
®
i-scan ID ISC.MR/PR/PRH101 and Host
Four different ways of data transmission between OBID
®
i-scan Readers and host (terminal, PC) are
possible. The ISO15693Host Commands and the Scan Mode are used for the data exchange be-
tween Transponder and host, whereas the Configuration Commands and the Control serves for
adapting the Reader parameters to the individual range of applications. The following chart shows
which method of data transmission is supported by which interface:
asynchronous interface
(RS232 / RS485)
Configuration Commands
√
Control Commands
√
ISO15693Host Commands
√
Scan-Mode
√
1.1. Configuration Commands and Control Commands
This method of data transmission is used for Reader configuration and the diagnosis via the asyn-
chronous interface or USB.
The Reader-configuration parameters will be stored in the Reader memory. To store the current con-
figuration during a power down of the Reader, the Reader-Configuration must be stored in the
EEPROM. After power up the Reader reads the configuration out of the EEPROM.
The Reader control is immediately processed and the response from the Reader contain status or
data information of the control command.
Host (Terminal / PC / ....) Reader
parameter- / control command
→
parameter received and stored / control
command processed
yes no
←
status /
data
error status
←
