Feig Electronic OBID i-scan ID ISC.PR101 User Manual

OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 101 of 131 H60301-3e-ID-B.doc
9.1.2. Fujitsu (MB89R116)
IC manufacturer identifier: 0x08
Memory organization: 256 x 8 Byte = 2kBit
Number of blocks 256 (user area: 0 – 249)
Block size 8 byte
Command
Code
Function Mode Comment
non-ad-
dressed
addressed select
0x01 Inventory
√
--
0x02 Stay Quiet
√
-
√
-
0x22 Lock Multiple Blocks
√√ √ √
WR-OPTION = 0 or 1
0x23
Read Multiple Blocks*
√√ √ √
DB-Size = 8
Security Status is always
0x00
0x24
Write Multiple Blocks
**
√√ √ √
DB-Size = 8,
WR-OPTION = 0 or 1
0x25 Select
√
-
√
-
0x26 Reset to Ready
√√ √ √
0x27 Write AFI
√√ √ √
WR-OPTION = 0 or 1
0x28 Lock AFI
√√ √ √
WR-OPTION = 0 or 1
0x29 Write DSFID
√√ √ √
0x2A Lock DSFID
√√ √ √
0x2B Get System Information
√√ √ √
0x2C
Get Multiple Block Security
Status
√√ √ √
* The Custom Specific Commands Read Multiple Blocks Unlimited [0xA5] will be used auto-
matically by the Reader.
** The WR-OPTION will be set automatically by the FEIG Readers if the RW-OPTION parameter
in “3.5. CFG4: Transponder Parameters” is set to “00: automatically set”. Up to two blocks
of data can be written for one request.
• ASK SUB-CARRIER must be configured in the reader (see: “3.5. CFG4: Transponder Pa-
rameters”)
