System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 56 of 131 H60301-3e-ID-B.doc
5.9. [0x74] Get Input (only for ID ISC.PRH101)
With this protocol the current status of the digital input IN1 (switch) can be checked.
Host → Reader
1 2 3 4...5
5 COM-ADR [0x74] CRC16
Host ← Reader
1 2 3 4 5 6...7
7 COM-ADR [0x74]
STATUS
1
INPUT CRC16
Input:
Bit: 7 6 5 4 3 2 1 0
Function:-------IN1
b0 digital input = inactive
b1 digital input = active
1
see ANNEX D: Index of Status Bytes
