9.1.7. Philips (I-Code SLI)
IC manufacturer identifier: 0x04
Memory organization: 32 x 4 Byte = 1kBit
Number of blocks 32 (user area: 0 – 27)
Block size 4 byte
Command
Code
Function Mode Comment
non-ad-
dressed
addressed select
0x01 Inventory
√
---
0x02 Stay Quiet
√
-
√
-
0x22 Lock Multiple Blocks
√√ √ √
WR-OPTION = 0 *
0x23 Read Multiple Blocks
√√ √ √
DB-Size = 4
Security Status is always
0x00
0x24 Write Multiple Blocks
√√ √ √
DB-Size = 4,
WR-OPTION = 0 *
0x25 Select
√
-
√
-
0x26 Reset to Ready
√√ √ √
0x27 Write AFI
√√ √ √
WR-OPTION = 0 *
0x28 Lock AFI
√√ √ √
WR-OPTION = 0 *
0x29 Write DSFID
√√ √ √
WR-OPTION = 0 *
0x2A Lock DSFID
√√ √ √
WR-OPTION = 0 *
0x2B Get System Information
√√ √ √
0x2C
Get Multiple Block Security
Status
√√ √ √
∗ The WR-OPTION will be set automatically by the FEIG Readers if the RW-OPTION parameter
in “CFG8 General” is set to “00: automatically set” (3.5. CFG4: Transponder Parameters).
