Feig Electronic OBID i-scan ID ISC.PR101 User Manual

OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 105 of 131 H60301-3e-ID-B.doc
9.1.5. Infineon (ISO Address mode) 0xE0
IC manufacturer identifier: 0x05
Memory organization:
SRF55V10P: 256 x 4 Byte = 8kBit SRF55V02P: 64 x 4 Byte = 2kBit
Number of blocks 256 (user area: 0...247) Number of blocks 64 (user area: 0...55)
Block size 4 byte Block size 4 byte
Command
Code
Function Mode Comment
non-ad-
dressed
addressed select
0x01 Inventory
√
--
0x02 Stay Quiet
√
-
√
-
0x22 Lock Multiple Blocks
√√ √ √
WR-OPTION = 0 *
0x23 Read Multiple Blocks
√√ √ √
DB-Size = 4
0x24 Write Multiple Blocks
√√ √ √
DB-Size = 4,
WR-OPTION = 0 *
0x25 Select
√
-
√
-
0x26 Reset to Ready
√√ √ √
0x27 Write AFI
√√ √ √
WR-OPTION = 0 *
0x28 Lock AFI
√√ √ √
WR-OPTION = 0 *
0x29 Write DSFID - - - -
0x2A Lock DSFID - - - -
0x2B Get System Information - - - -
0x2C
Get Multiple Block Security
Status
√√ √ √
Custom specific commands
0x10 Read
√√ √ √
DB-Size = 4
0x30 Write
√√ √ √
DB-Size = 4,
WR-OPTION = 0 *
0x90 Write Byte
√√ √ √
WR-OPTION = 0 *
The WR-OPTION will be set automatically by the FEIG Readers if the RW-OPTION parameter in
“CFG4 Transponder Parameters” is set to “00: automatically set” (3.5. CFG4: Transponder Pa-
rameters).
