9.1.10. Texas Instruments (Tag-it™ HF-I Plus)
The command codes listed in the following table support the various Transponder commands and
operations that are available for Tag-it™ HF-I PlusTransponders.
IC manufacturer identifier: 0x07
Product ID / Config : (xxxx / nnn)
Tag-it™ HF-I Plus = b0000 000 or
= b1000 000
Memory organization: 64 x 4 Byte = 2kBit user data
Number of blocks 65 (user area: 0...63)
Block size 4 byte
Command
Code
Function Mode Comment
non-ad-
dressed
addressed select
0x01 Inventory
√
---
0x02 Stay Quiet
√
-
√
-
0x22 Lock Block
√√ √ √
WR-OPTION = 1 **
0x23 Read Multiple Blocks
√√ √ √
DB-Size = 4
WR-OPTION = 1 **
0x24 Write Multiple Blocks - - - -
0x25 Select
√
-
√
-
0x26 Reset to Ready
√√ √ √
0x27 Write AFI
√√ √ √
WR-OPTION = 1 **
0x28 Lock AFI
√√ √ √
WR-OPTION = 1 **
0x29 Write DSFID
√√ √ √
WR-OPTION = 1 **
0x2A Lock DSFID
√√ √ √
WR-OPTION = 1 **
0x2B Get System Information
√√ √ √
0x2C
Get Multiple Block Security
Status
√√ √ √
Custom specific commands
0xA2 Write_2_Blocks
√√ √ √
0xA3 Lock_2_Blocks
√√ √ √
** The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter
in “CFG4 General Transponder Param” is set to “00: automatically set” (3.5. CFG4:
Transponder Parameters).
By using the “non-addressed ” mode the WR-OPTION must be set manually to “WR-
OPTION = 1”.
Note:
