OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 32 of 131 H60301-3e-ID-B.doc
3.7. CFG6: Scan-Mode1
The parameters of the CFG6 configuration block contain Scan-Mode settings. To enable Scan-Mode
the SCAN-MODE bit in the configuration block CFG1 (3.2. CFG1: Interface) must be set.
Byte 0 1 2 3 4 5 6
Contents SCANNER-
MODE
0x00 0x00 SCAN-DATA 0x00 0x00 SCAN-LOCK-
TIME
Default
MR101
0x02 0x01 0x00
Default
PRH101
0x80 0x01 0x00
Byte 7 8 9 10 11 12 13
Contents SCAN-LOCK-
TIME
0x00 0x00 0x00 DB-ADR D-LGT D-START
Default
MR101
0x0A
1 sec.
0x05 0x04 0x00
Default
PRH101
0x0A
1 sec.
0x05 0x04 0x00
SCANNER-MODE
defines the mode of the scanner.
Bit: 7 6 5 4 3 2 1 0
Function Trigger 0 0 0 0 mode
mode:
b000: Single Read: (active for read duration – stops after good read)
When all Transponders in detection range has been decoded, the Reader
will stop the scan. The Reader must be triggered again to read other Trans-
ponders.
b010: Continuos Read:
The Reader will read as much Transponders as it can decode regardless
whether it is the same or not. This mode is mainly used for demonstration
and diagnostic.
Trigger:
b0: Trigger disabled:
The Reader scans all the time. However, this mode increase the current
consumption
b1: Trigger enabled: (only ID ISCPRH101)
The Reader start the scan, if the trigger is activated by the external switch.
Note
If Trigger is enabled an not activated by the external switch, the RF-
field will be switched off.
