OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 21 of 131 H60301-3e-ID-B.doc
3.1. CFG0: Reserved
The configuration block CFG0 is reserved for future use.
Byte 0 1 2 3 4 5 6
Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Default
Byte 7 8 9 10 11 12 13
Contents 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Default
3.2. CFG1: Interface
The parameters of the CFG1 configuration block contain the data communication settings.
Byte 0 1 2 3 4 5 6
Contents COM-ADR 0x00
BAUD
1
TRANS-
FORM
1
ADVANCED
MODE
0x00 TR-
RESPONSE-
TIME
Default 0x00 0x08 0x01 0x00 0x00
0x00 38400 Baud e,8,1
USB-Ver-
sion
0x00 0x00 0x00 0x00 0x00
Byte 7 8 9 10 11 12 13
Contents TR-
RESPONSE-
TIME
0x00 0x00 0x00 0x00 INTERFACE READER -
MODE
Default 0x1E 0x01 MR/PR: 0x00
PRH: 0x01
3 sec.
USB-Ver-
sion
0x1E 0x00
COM-ADR:
Bus address of the Reader (0 .. 254) for communication via the asynchronous interface, es-
pecially for applications with the RS485 interface.
Notes:
• Do not configure address 255!
