9.1.11. Texas Instruments (Tag-it™ HF-I Standard, Tag-it™ HF-I Pro)
The command codes listed in the following table support the various Transponder commands and
operations that are available for Tag-it™ HF-I Standard and Tag-it™ HF-I Pro Transponders.
IC manufacturer identifier: 0x07
Product ID / Config : (xxxx / nnn)
Tag-it™ HF-I Standard = b1100 000
Tag-it™ HF-I Pro = b1100 010
Memory organization: 8 x 4 Byte = 256Bit user data
Number of blocks 11 (user area: 0...7)
Block size 4 byte
Command
Code
Function Mode Comment
non-addres-
sed
addressed select
0x01 Inventory
√
---
0x02 Stay Quiet
√
-
√
-
0x22 Lock Block
√√ √
-
WR-OPTION = 1 **
0x23 Read Multiple Blocks
√√ √
-
DB-Size = 4
0x24 Write Multiple Blocks
√√ √
-
DB-Size = 4
WR-OPTION = 1
**
0x25 Select - - - -
0x26 Reset to Ready - - - -
0x27 Write AFI - - - -
0x28 Lock AFI - - - -
0x29 Write DSFID - - - -
0x2A Lock DSFID - - - -
0x2B Get System Information - - - -
0x2C Get Multiple Block Security
Status
-- - -
Custom specific commands
0xA4 Kill
√
-
√
-
only Pro
0xA5 WriteSingeBlockPwd
√
-
√
-
only Pro
** The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame-
ter in “CFG4 Transponder Paramters” is set to “00: automatically set”
(3.5. CFG4: Transponder Parameters).
Note:
• Only one block is allowed for Read Multiple Blocks in non addressed mode
