6.1.12. [0x2B] Get System Information
This command reads the system information from one Transponder.
REQUEST-DATA
4 5 (6...13)
0x2B MODE UID
RESPONSE-DATA (STATUS = 0x95)
5
ISO-ERROR
RESPONSE-DATA
5 6...13 14 15...16 17
DSFID UID AFI MEM-SIZE IC-REF
0x00
Only LS
32bits valid
Manufacturer
Code
MEM SIZE Chip Version
MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 0 ADR
ADR:
b000 non-addressed
b001 addressed
b010 selected
UID:
Read-only serial number of the Transponder. The UID is required only in the addressed
mode.
ISO-ERROR:
ISO15693 error code of Transponder response. This byte is only available if STATUS = 0x95.
DSFID:
Data Storage Format Identifier of the Transponder.
UID:
The LSB (32bits) from the Read only Serial Number of the Transponder.
AFI:
Application Family Identifier. If not supported by the Transponder, this value will return 0x00.
Manufacturer Code:
Manufacturer specific code (see: ANNEX A: Codes of Transponder Types)
