4.3. [0x82] Save Configuration
By the command Save Configuration each configuration block of the RAM can be stored in EEPROM.
Host → Reader
1 2 3 4 5-6
6 COM-ADR [0x82] CFG-ADR CRC16
Host ← Reader
1 2 3 4 5-6
6 COM-ADR [0x82]
STATUS
1
CRC16
CFG-ADR
2
:
Bit: 7 6 5 4 3 2 1 0
Function 0 MODE CFGn: Address of Configuration Block
CFGn: memory-address of the required configuration block
MODE: specifies one or all configuration blocks
b0 configuration block specified by CFGn
b1 all configuration blocks
Note:
• To store RAM configuration after power down use 4.3. [0x82] Save Configuration
• A save configuration to EEPROM with reserved configuration blocks will result in error
code 0x16.
1
see ANNEX D: Index of Status Bytes
2
see chapter 3. Configuration Parameters (CFG)
