OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 16 of 131 H60301-3e-ID-B.doc
2. Asynchronous Interface
2.1. Data Format and Protocol Frames
The Reader ID ISC.MR/PR/PRH101 can be configured by an asynchronous interface and data may be
written on Transponders or read from Transponders. The communication between Reader and con-
nected host (terminal, PC, etc.) is executed by means of fixed protocols. The used protocol is intended
for data bus use and is equipped with a bus address.
During data transfer via the asynchronous interface the Reader supplies the required data or a status
byte. The reply contain the transmitted control byte.
There is no reply from the Reader if there is a protocol frame failure.
Protocol frame: Standard Protocol-Length (up to 255 Byte)
Host → Reader
1 2 3 4...n-2 n-1 n
LENGTH = n COM-ADR
CONTROL-
BYTE
PROTOCOL-
DATA
LSB-CRC16 MSB CRC16
Host ← Reader
1 2 3 4 (5...n-2) n-1 n
LENGTH = n COM-ADR
CONTROL-
BYTE
STATUS
1
(PROTOCOL-
DATA)
LSB-CRC16 MSB CRC16
Protocol frame: Advanced Protocol-Length
Reader ← Host
1 2 3 4 5 (6...n-2)
STX
(0x02)
MSB
ALENGTH
LSB
ALENGTH
COM-ADR
CONTROL-
BYTE
(DATA)
©
n-1 n
ª
MSB
CRC16
LSB
CRC16
Host ← Reader
1 2 3 4 5 6 (7...n-2)
STX
(0x02)
MSB
ALENGTH
LSB
ALENGTH
COM-ADR
CONTROL-
BYTE
STATUS (DATA)
©
n-1 n
ª
MSB
CRC16
LSB
CRC16
1
see ANNEX D: Index of Status Bytes
