8.2.3. [0xA2] Get Log Status
This command reads the status flags for the logging of the measurement values.
REQUEST-DATA
5 6 (7-14)
0xA2 MODE UID
RESPONSE-DATA (STATUS = 0x95)
5
ISO-ERROR
RESPONSE-DATA
5 6 7-8 9-10 11-12 13-14
Logflags Logpointer LogLimitLo LogLimitHi Logperiode Timerticks
MODE:
Bit: 7 6 5 4 3 2 1 0
Function - - - - - ADR
ADR:
ADR
b000 non-addressed
b001 addressed
b010 selected
UID:
Read-only serial no. of the transponder. The UID is required only in the addressed mode.
ISO-ERROR:
ISO error code of transponder response. This byte is only available if STATUS = 0x95.
Logflags: The type of measurement.
Logpointer: Pointer of the next measurement value
LogLimitLo: Lower limit for measurement value
LogLimitHi: Higher limit for measurement value
Logperiode: Range of the measure.
Timerticks: Defines how many times the measurement interval runs off.
