OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 31 of 131 H60301-3e-ID-B.doc
3.6. CFG5: Anticollision
The parameters of the CFG5 configuration block contain anticollision settings.
Byte 0 1 2 3 4 5 6
Contents
TIMESLOTS
1
0x00 0x00 0x00 0x00 0x00 0x00
Default 0x02
Byte 7 8 9 10 11 12 13
Contents 0x00 0x00 0x00 0x00 ONT 0x00 0x00
Default 0x01
TIMESLOTS: (only I-Code 1 and I-Code EPC/UID Transponders)
Number of timeslots with which Transponders will be read.
TIMESLOTS Number of Timeslots ID ISC.MR/PR/PRH101
0x03
0x02
0x01
0x00
16
8
4
1
√
√
√
√
• Each I-Code 1 and I-Code EPC/UID Transponder responds in a chosen timeslot. Choosing
too much timeslots compared to the number of Transponders in the antenna field causes
that only a small number of Transponders can be selected at one time. On the other hand
are too many timeslots very time consuming. The optimum number of timeslots is about
twice the number of Transponders expected in the antenna field at the same time.
ONT:
Defines which Transponder will send to the host.
Bit: 7 6 5 4 3 2 1 0
Driver 0 0 0 0 0 0 0 ONT
ONT:
b0: all Transponders in the field will be send to the host. The Reader performs a
RF Reset before any command reads a UID
b1: only the new selected Transponders will sent to the host
Note:
If 1 timeslot is set and the CRC on an I-Code EPC is wrong the serial number will be transferred
and the status is set to “[0x02] Data False”
1
A plausibility check is performed by writing this parameter to the Reader. If an error occurs the Reader an-
swers with STATUS = 0x11.
