6.1.13. [0x2C] Get Multiple Block Security Status
This command reads the public block security status from one Transponder.
REQUEST-DATA
4 5 (6...13) 6 / (14) 7 / (15)
0x2C MODE UID DB-ADR DB-N
RESPONSE-DATA (STATUS = 0x95)
5
ISO15693
ERROR
RESPONSE-DATA
5 6
DB-N SEC-STATUS
Repeated DB-
N times
MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 0 ADR
ADR:
b000 non-addressed
b001 addressed
b010 selected
UID:
Read-only serial number of the Transponder. The UID is required only in the addressed mode.
DB-ADR:
First block number from which security status is requested. First block number can be any
value between 0 and 255.
DB-N:
Number of Security data blocks to be read from the Transponder, starting at DB-ADR.
The maximum number of DB-N, depends on DB-Size.
DB-Size Max. DB-N
4 0x20 ->32
8 0x10 ->16
x = 128 / x
ISO15693 ERROR:
ISO15693 ERROR code of Transponder response. This byte is only available if STATUS =
0x95.
SEC-STATUS:
Block security status .
Note:
This command is only available for ISO15693 Transponders.
