OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 85 of 131 H60301-3e-ID-B.doc
8.2.2. [0xA1] Set Log
This command starts the recording of the temperature of the KSW - TempSens.
REQUEST-DATA
5 6 (7 - 14) 8 (15) 9 (16) 10-11 (17-18)
0xA1 MODE UID Logflags Logpointer Logperiode
©
12-13 (19-20) 14-15 (21-22)
ª
LogLimitLo LogLimitHi
RESPONSE-DATA (STATUS = 0x95)
5
ISO-ERROR
MODE:
Bit: 7 6 5 4 3 2 1 0
Function - - - - - ADR
ADR:
ADR
b000 non-addressed
b001 addressed
b010 selected
ISO-ERROR: (only ISO transponders)
ISO error code of transponder response. This byte is only available if STATUS = 0x95.
UID:
Read-only serial no. of the transponder. The UID is required only in the addressed mode.
Logflags: The type of measurement.
Logpointer: Pointer of the next measurement value.
Logperiode: Range of the measure. .
LogLimitLo: Lower limit for measurement value
LogLimitHi: Higher limit for measurement value
