OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 82 of 131 H60301-3e-ID-B.doc
DB:
Requested data block. The block size is defined by DB-SIZE.
Notes:
• Only one Transponder can be read in the non-addressed mode.
8.1.2. [0x30] Write
This command writes one or more data blocks in my-d custom mode. The user can decide to use the
customer command or the command in ISO-Mode ([0x24] Write Multiple Blocks).
REQUEST-DATA
5 6 (7...14) 7 / (15) 8 / (16) 9 / (17) 10...n / (18...n)
0x30 MODE UID DB-ADR DB-N DB-SIZE DB
Repeated DB-N times
RESPONSE-DATA (STATUS = 0x03)
5
DB-ADR-E
RESPONSE-DATA (STATUS = 0x95)
5 6
ISO-ERROR DB-ADR-E
MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 0 ADR
ADR:
b000 non-addressed
b001 addressed
b010 selected
UID:
Read-only serial number of the Transponder. The UID is required only in the addressed
mode.
DB-ADR:
Address of the first data block to be written to the Transponder. First block can be any value
between 0 and 255.
DB-N:
Number of data blocks to be written to the Transponder, starting at DB-ADR. The maximum
number of DB-N = 16 (128 bytes).
DB-SIZE:
Number of bytes of one data block(8 bytes).
