Feig Electronic OBID i-scan ID ISC.PR101 User Manual

OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 125 of 131 H60301-3e-ID-B.doc
ANNEX G: Memory Model I-Code 1 Transponders
The memory is subdivided into areas with an access size of 4 bytes each.
I-Code 1
address
I-Scan
address
contents description comment
0...1 - UID Serial-No (8 Bytes) read-only
2 C0 Config Write Access Conditions
3 C1 Special Function
(EAS, QUIET-Bit)
4 C2 Family Code /
Application ID
read/write
read-only configurable
5 D0 User User-Memory
6D1
7D2
8D3
9D4
10 D5
11 D6
12 D7
13 D8
14 D9
15 D10
read/write
read only configurable
Note:
During the writing of data on a Transponder, it must be ensured that the Transponder stays
completely in the antenna field for the whole time.
S-No.:
This block contain the unique read only 64 bit UID of the Transponder.
Bit Byte Function
0-7 0 MSB UID
8-15 1
16-23 2
24-31 3
32-39 4
40-47 5
48-55 6
56-63 7 LSB UID
