Config Block 0:
This config block activates protective functions of the Transponder.
The bits can be set only to 0 and never be reversed to 1. If block C0 is set into write protected state,
no further protective functions can be activated (hardware write protected state).
Bit Byte Function Operation
Block I-Scan Block I-Code 1
0 0 ”1” = r/w, ”0” = ro D0 5
1 "1" = r/w, ”0” = ro D1 6
2 "1" = r/w, ”0” = ro D2 7
3 "1" = r/w, ”0” = ro D3 8
4 ”1” = r/w, ”0” = ro D4 9
5 "1" = r/w, ”0” = ro D5 10
6 "1" = r/w, ”0” = ro D6 11
7 "1" = r/w, ”0” = ro D7 12
8 1 "1" = r/w, ”0” = ro D8 13
9 "1" = r/w, ”0” = ro D9 14
10 ”1” = r/w, ”0” = ro D10 15
11 ---
12 ---
13 ---
14 ---
15 ---
16-23 2 - - -
243---
25 ---
26 ---
27 ”1” = r/w, ”0” = ro C2 4
28 ”1” = r/w, ”0” = ro C1 3
29 "1" = r/w, ”0” = ro C0 2
30 ”0” = ro S-NO 1
31 ”0” = ro S-NO 0
