6.1.15. [0xA1] Write Config Block
This command writes one config block of the i-scan memory model (see ANNEX G: Memory Model I-
Code 1 Transponders).
REQUEST-DATA
4 5 6...13 14 15...18
0xA1 MODE UID CB-ADR CB
MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 0 ADR
ADR:
b001 addressed
UID:
Read-only serial number of the Transponder.
CB-ADR:
Address of the config block to be read from the Transponder.
CB:
Config block to be written to the Transponder.
Note:
• This command is only available for I-Code 1 Transponders.
• The command is not available if the Reader is set to original I-Code Memory Model.
(see 3.5. CFG4: Transponder Parameters, I-Code-Mode).
To write the Config Block 0,1,2 can now be done with Write Multiple Blocks [0x24] on the
original I-Code Address 2,3,4.
When using ISO15693 Transponders the command 6.1.3. [0x22] Lock Multiple Blocks should
be used.
