OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 28 of 131 H60301-3e-ID-B.doc
3.5. CFG4: Transponder Parameters
The parameters of the CFG4 configuration block contain general Transponder settings.
Byte 0 1 2 3 4 5 6
Contents I-Code-
MODE
FAM-CODE APP-ID 0x00 ISO 15693
MODE
ISO 15693
AFI
ISO 15693
OPTION
Default 0x00 0x00 0x00 0x0B 0x00 0x00
Byte 7 8 9 10 11 12 13
Contents CUSTOMER
OPTION
0x00 0x00 0x00 0x00 0x00 ISO-Block-
size
Default 0x00 0x04
I-Code-MODE: (only I-Code Transponder)
Bit: 7 6 5 4 3 2 1 0
Function Mapping 0 0 0 0 0 0 0
Mapping:
b0: FEIG Memory Model (default)
b1: Original I-Code Memory Model
Note:
• If Mapping is set to “original I-Code Memory Model” the ISO15693 Host Command
Read Config Block[0xA0] and Write Config Block [0xA1] will not be available.
To change the Config Block 0,1,2 can now be done with Write Multiple Blocks [0x24]
on the original I-Code Address 2,3,4.
FAM-CODE: (only I-Code 1 Transponders)
Family Code to select a Transponder
APP-ID: (only I-Code 1 Transponders)
Application ID to select a Transponder
Note:
If FAM-CODE and APP-ID are zero, all I-Code 1 Transponders will response. Otherwise only the
Transponders with matching FAM-CODE and APP-ID will respond.
