ISO 15693 MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 AFI NO-TS DATA-
RATE
SUB-
CARRIER
MOD DATA
CODING
DATACODING
b0: - do note use -
b1: Fast Mode (1 / 4)
MOD
b0: - do note use –
b1: 10%
SUB-CARRIER
b0: ASK (one sub-carrier)
b1: - do note use -
DATA-RATE
b0: - do note use -
b1: high
NO-TS
b0: 16 timeslots
b1: 1 timeslot
Note:
Anticollision is only possible if NO-TS=16.
AFI
b0: disabled
b1: enabled
ISO 15693 AFI:
Application Family Identifier to select a Transponder
ISO 15693 OPTION:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 WR-OPTION 0 0
WR-OPTION:
b00: automatically set
b10: Tag Option = 0
b11: Tag Option = 1
Note:
• If WR-OPTION is automatically set, the Reader sets the WR-OPTION to 0, if the
ISO15693Host Command is in non-addressed mode. In the case of a Tag-it HF-I Stan-
dard/Plus/Pro the WR-OPTION must be set to 1 for all Write and Lock commands to
respond properly.
• See chapter 9.1. Supported ISO15693 Host commands for ISO15693 Transponders for more
details about the correct WR-OPTION.
