Feig Electronic OBID i-scan ID ISC.PR101 User Manual

OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 104 of 131 H60301-3e-ID-B.doc
9.1.4. Infineon (my-d page mode) 0x60
IC manufacturer identifier: 0x05
Memory organization:
SRF55V10P: 128 x 8 Byte = 8kBit SRF55V02P: 32 x 8 Byte = 2kBit
Number of blocks 128 (user area: 3...127) Number of blocks 32 (user area: 3...31)
Block size 8 byte Block size 8 byte
Command
Code
Function Mode Comment
non-ad-
dressed
addressed select
0x01 Inventory
√
--
0x02 Stay Quiet
√
-
√
-
0x22
Lock Multiple Blocks**
√
-
√√
WR-OPTION = 0 *
0x23
Read Multiple Blocks**
√
-
√√
DB-Size = 8
Security Status is always
0x00
0x24
Write Multiple Blocks**
√
-
√√
DB-Size = 8,
WR-OPTION = 0 *
0x25 Select
√
-
√
-
0x26 Reset to Ready
√√ √ √
0x27 Write AFI
√√ √ √
WR-OPTION = 0 *
0x28 Lock AFI
√√ √ √
WR-OPTION = 0 *
0x29 Write DSFID - - - -
0x2A Lock DSFID - - - -
0x2B Get System Information - - - -
0x2C
Get Multiple Block Security
Status
-- - -
∗ The WR-OPTION will be set automatically by the FEIG Readers if the RW-OPTION parameter
in “3.5. CFG4: Transponder Parameters”
** The Custom Specific Commands Read [0x10], Write [0x30] and the Write Byte [0x90] will be
used automatically by the Reader.
