OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 54 of 131 H60301-3e-ID-B.doc
5.8. [0x71] Set Output
The command [0x71] is used for temporary limited or unlimited activation of the digital outputs or dis-
plays (LED, beeper) of the Reader.
Each output takes on the state defined by the byte "OS" for the period of time specified in the protocol.
The flashing frequency is defined by the byte "OSF". Via this protocol, the beeper and the LEDs can
be switched on or off for the indicated period of time. If the Reader receives a protocol "Set Output", all
times that have been active until then are overwritten by the new times specified in the protocol if they
are > 0.
Host → Reader
1 2 3 4,5 6,7
13 COM-Adr [0x71] OS OSF
°
8,9 10,11 12,13
ª
OS-Time 0x00 CRC16
Host ← Reader
1 2 3 4 5,6
6 COM-Adr [0x71]
Status
1
CRC16
OS:
The word OS (Output State) defines the status of the signal emitters (LEDs and beeper) dur-
ing the time defined in "OS-time". The signal emitters can be selected single or in a group.
Bit: 15 14 13 12 11 10 9 8
Function: 0 0 0 0 0 0 0 0
°
7 6 5 4 3 2 1 0
ª
0 0 Beeper mode
(only PRH101)
LED red
mode
LED grn
mode
LED grn-/LED red-/Beeper-mode (PRH: LED blue instead of LED red):
b00 UNCHANGED OS-Time has no effect on the status of the signal emitter
b01 ON Signal emitter for OS-Time = active
b10 OFF Signal emitter for OS-Time = inactive
b11 FLASH Signal emitter for OS-Time = with "OSF" alternating
1
see ANNEX D: Index of Status Bytes
