OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 81 of 131 H60301-3e-ID-B.doc
8.1. Infineon Custom Commands
These commands supports the functions of the Infineon transponder
8.1.1. [0x10] Read
This command reads one or more data blocks. The user can decide to use the customer command or
the command in ISO-Mode ([0x23] Read Multiple Blocks).
REQUEST-DATA
5 6 (7...14) 7 / (15) 8 / (16)
0x10 MODE UID DB-ADR DB-N
RESPONSE-DATA (STATUS = 0x95)
5
ISO-ERROR
RESPONSE-DATA
5 6 7 8...n
DB-N DB-SIZE SEC-STATUS DB
Repeated DB-N times
MODE:
Bit: 7 6 5 4 3 2 1 0
Function 0 0 0 0 0 ADR
ADR:
b000 non-addressed
b001 addressed
b010 selected
UID:
Read-only serial number of the Transponder. The UID is required only in the addressed
mode.
DB-ADR:
First block number to be read. First block can be any value between 0 and 255.
DB-N:
Number of data blocks to be read from the Transponder, starting at DB-ADR.
The maximum number of DB-N is 16 (128 bytes)
ISO-ERROR: (only ISO15693 Transponders)
ISO15693 error code of Transponder response. This byte is only available if STATUS = 0x95.
DB-SIZE:
Number of bytes of one data block(8 Bytes).
SEC-STATUS:
Block security status of following data block. Sec-Status is not supported, this value will return
0x00.
