OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 22 of 131 H60301-3e-ID-B.doc
• Via the COM-Adr 255 in the send protocol, the Reader is able to be addressed at any
time. It answers then with the configured address.
• Not available by the USB-Reader
BAUD
1
:
By means of this byte the baud rate of the asynchronous interface can be defined.
5: 4800 baud
6: 9600 baud
7: 19200 baud
8: 38400 baud
Note:
• Changing of BAUD only becomes effective after writing / saving configuration block
CFG1 to EEPROM and a reset of the Reader.
• The Reader set the baud rate to 38400 baud, if the user set an invalid baudrate.
• Not available by the USB-Reader
TRANS-FORM
2
:
By means of this byte, several parameters for the data transmission format of the asynchro-
nous interface can be defined.
Bit: 7 6 5 4 3 2 1 0
Function: 0 0 0 0 S D P
P: Kind of Parity
b00: no Parity
b01: even Parity
b10: odd Parity
b11: - do not use -
D: Number of Data Bits
b0: 8 Data Bits
b1: - do not use -
S: Number of Stop Bits
b0: 1 Stop Bit
b1: - do not use -
1
A plausibility check is performed by writing this parameter to the Reader. If an error occurs the Reader an-
swers with STATUS = 0x11.
2
A plausibility check is performed by writing this parameter to the Reader. If an error occurs the Reader an-
swers with STATUS = 0x11.
