OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 23 of 131 H60301-3e-ID-B.doc
Note:
• Changing of TRANS-FORM only becomes effective after writing / saving configura-
tion block CFG1 to EEPROM and reset of the Reader.
• Always 8 Data Bits and 1 Stop Bits should be used
• Not available by the USB-Reader
ADVANCED MODE:
Bit: 7 6 5 4 3 2 1 0
Function: 0 0 0 0 0 0 0
Bit0
By setting this bit the Reader behaves like MR/PR/PRH100. On a request in normal mode the
readers response is also in normal mode.
Bit0:
b0: reader automatically answers in advanced mode, if data length is longer
than 255 Byte.
b1: reader always answers in normal mode. If there is data length longer than
255 Byte the reader sets MORE Byte.
TR-RESPONSE-TIME:
By means of this parameter the maximum duration for the Transponder command can be de-
fined.
The TR-RESPONSE-TIME starts after the Reader has received a new command. At the lat-
est after the TR-RESPONSE-TIME elapsed the Reader will send an answer protocol. In this
case, the current commands between Reader and Transponder are aborted. If this time is too
short the Interface Status “0x83 RF Communication Error“ will appear.
max. response duration
TR-RESPONSE-TIME 0...65535 * 100 ms
Note:
• TR-RESPONSE-TIME has no effect with the protocols for Reader Configuration and
the protocols for Reader Control.
• The TR-RESPONSE Time must be < “Block Timeout” in the Host COM-Port settings.
